Aluminum Body Truck

Share to:

The tyre transportation truck is mainly used for the distribution of automobile tyre assemblies. It can realize automatic loading and unloading of the tyre assembly by just clicking one button. Our tyre transport vehicle has electric control that is reliable and durable, which is the best choice for automobile tyre transport vehicles. It also has large type transport amount and fast transport speed, which can transport the tyre to anyplace that one wants.


The rear door of the our type transport vehicle body can be optionally equipped with two locking levers or no rear door structure, and the rear door panel is available in corrugated board form. The chassis of tyre transport vehicle can be optional according to buyer’s requirements. The side protection bar adopts Q235A steel plate that is connected with column (angle steel), and the side protection device and the box body frame are bolted. The rear protection adopts Q235A channel steel and is connected to the frame using connecting materials. The height of the rear protection device from the ground is 510mm.


Henan SWAN Vehicle CO.,LTD is w well-known special vehicle manufacturer, which offers many types of special vehicles for sale, such as LED advertising truck, stage truck, exhibition truck, wing van truck, mobile shop truck, motorhome & RV, logistic transportation truck etc. Welcome to contact us for free quotation if one is interested to get further info of our tyre transportation truck for sale.

Commodity:Aluminum Box Vehicle
Public Announcement Batch of Vehicle:298Gross Weight:35,000kg
Rated Weight:26700kg, 27000kgCurb Weight:8300kg, 8000kg
Max. Speed:(km/h)Approach/Departure Angle(°):-/11,-/13
Front/Rear Suspension:-/2710,-/2390Number of Springs:-/7/7
Number of Tyre:8Type of Tyre:11R22.5   16PR,10.00R20 16PR
Front Tread:-Rear Tread:1840/1840
Axle:2Wheelbase:7980+1310
Overall Dimension(mm):13590,13000*2550*3990(L*W*H)
Dimension of Box Body(mm):13320,12730*2420*2400(L*W*H)
